Phaser 6180MFP Multifunction Printer Service Manual 10-41
Plug/Jack and Wiring Diagrams
Signal Line Name Description
CLK Controls signal of the EEPROM Fuser.
DATA
STS Provides Heat Roll surface temperature data measured
by the Humidity/Temperature Sensor for detecting high
temperature (Analog value).
VC Provides temperature data measured by the Humidity/
Temperature Sensor for controlling the temperature
(Analog value).
VD
FUSER EXIT SENSED (L)
+3.3 VDC
Detects signal of the Fuser Exit by the Photo Sensor
(Exit Sensor).
FUSER ON Displays lighting signal of the Fuser Lamp.
RELAY TEST LOW Tests signal of the LVPS (used in production process
only)
RELAY TEST HIGH

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
