Xerox Phaser 6180MFP Service Manual

10-52 Phaser 6180MFP Multifunction Printer Service Manual
Plug/Jack and Wiring Diagrams
Signal Line Name Description
SCN-/A Drives control signal of the Scanner Motor.
SCN-A
SCN-/B
SCN-B
ADCLK+ Controls signal of the CCD Board.
ADCLK-
TG
ID8- Controls image date of the document by the CCD.
ID8+
ID7-
ID7+
ID6-
ID6+
ID5-
ID5+
ID4-
ID4+
INV Controls signal of the Lamp Inverter.
AFE*RST Controls signal of the CCD Board.
AFEDATA
AFECLK
AFE*CS
HP SENSED (H) +5 VDC Detects Home Position signal of the Carriage by the
Photo Sensor.
