Xerox Phaser 6180MFP Service Manual

A-10 Phaser 6180MFP Multifunction Printer Service Manual
Reference
825-037 NUM
CHECK
TIMER
Interval duration for the
same destination.
1 to 255 sec 60
825-109 ONHOOK
LCS RATE
Offhook detection threshold
for SiDAA LCS.
1 to 100% 75
825-074 TIME TO
DETECT
DIALTONE
Dial tone detection timeout
duration.
0 to 255 sec 20
825-079 ONHOOK
DETECT
TIME
ONHOOK detection duration. 10 to 255
(20ms/1 step)
65
825-110 DIS
DIALTONE
PATTERN
Dial tone pattern detection.
■ 0:Disable
■ 1:Enable
0
825-111 DIALTONE
ONOFFPT
MIN
Minimum dial tone ON/OFF
duration.
8 to 255
(10ms/1 step)
10
825-112 DIALTONE
ONOFFPTN
MAX
Maximum dial tone ON/OFF
duration.
8 to 255
(10ms/1 step)
100
825-605 CNG STOP
SELECT
Select CNG stop criterion.
■ 0:CED and V.21
■ 1:CED
■ 2:V.21
0
825-622 G3M TX
MODEM
SPEED
Outbound transfer mode
(rate).
■ 0:Fallback
partner
■ 1:Fallback
V27ter
■ 2:V27ter (2400/
4800bps)
■ 3:V29 (7200/
9600bps)
■ 4:V33 (12000/
14400bps)
■ 5:V17 (7200/
9600/12000/
14400bps)
0
825-623 G3M RX
MODEM
SPEED
Inbound transfer mode
(rate).
■ 0:V27ter+V29+V
33+V17
■ 1:V27ter
(2400bps)
■ 2:V27ter (2400/
4800bps)
■ 3:V29 (7200/
9600bps)
■ 4:V27ter+V29
■ 5:V27ter+V29+V
33
0
Chain Link (Continued)
Chain
Link
Parameter
Name Contents Setting Range
Default
Value
