CHAPTER65 Testing SIP Signaling Calls
Mediant 1000 Gateway & E-SBC | User's Manual
3. Configure a test call according to the parameters described in the table below.
4. Click Apply, and then save your settings to flash memory.
Table 65-1: Test Call Rules Table Parameter Descriptions
Parameter Description
Common
'Index' Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
'Endpoint URI'
endpoint-uri
[Test_Call_EndpointURI]
Defines the endpoint's URI. This can be defined as a user
or user@host. The device identifies this endpoint only by
the URI's user part. The URI's host part is used in the
SIP From header in REGISTER requests.
The valid value is a string of up to 150 characters. By
default, the parameter is not configured.
Note: The parameter is mandatory.
'Called URI'
called-uri
[Test_Call_CalledURI]
Defines the destination (called) URI (user@host).
The valid value is a string of up to 150 characters. By
default, the parameter is not configured.
'Route By'
route-by
[Test_Call_RouteBy]
Defines the type of routing method. This applies to
incoming and outgoing calls.
â– [1] IP Group = (Default) Calls are matched by (or
routed to) an IP Group. To specify the IP Group, see
the 'IP Group' parameter in the table.
â– [2] Dest Address = Calls are matched by (or routed
to) a destination IP address. To configure the
address, see the 'Destination Address' parameter in
the table.
Note:
â– If configured to Dest Address:
- 1069 -
