CHAPTER65 Testing SIP Signaling Calls
Mediant 1000 Gateway & E-SBC | User's Manual
Parameter Description
✔ You must assign a SIP Interface (see the 'SIP
Interface' below).
✔ The IP Profile of the default IP Group (ID 0) is
used. You can use a different IP Profile, by
specifying an IP Group in the 'IP Group'
parameter (below).
â– For REGISTER messages, if configured to IP
Group, only Server-type IP Groups can be used.
'IP Group'
ip-group-id
[Test_Call_IPGroupName]
Assigns an IP Group. This is the IP Group that the test
call is sent to or received from.
By default, no value is defined.
To configure IP Groups, see Configuring IP Groups.
Note:
â– The parameter is applicable if you configure the
'Route By' parameter to IP Group.
â– You can also use this parameter if you configure the
'Route By' parameter to Dest Address. This allows
you to associate an IP Profile (that is assigned to the
specified IP Group) with the Test Call. The Test Call
is not routed to the IP Group, but uses only its IP
Profile.
â– The IP Group is used for incoming and outgoing calls.
'Destination Address'
dst-address
[Test_Call_DestAddress]
Defines the destination host.
The valid value is an IP address[:port] in dotted-decimal
notation or a DNS name[:port].
Note: The parameter is applicable only if you configure
the 'Route By' parameter to Dest Address.
'SIP Interface'
sip-interface-name
[Test_Call_SIPInterfaceName]
Assigns a SIP Interface. This is the SIP Interface to
which the test call is sent and received from.
By default, no value is defined.
To configure SIP Interfaces, see Configuring SIP
Interfaces.
Note: The parameter is applicable only if the 'Route By'
parameter is configured to Dest Address.
'Application Type'
application-type
[Test_Call_ApplicationType]
Defines the application type for the endpoint. This
associates the IP Group and SRD to a specific SIP
interface. For example, assume two SIP Interfaces are
configured in the SIP Interfaces table where one is set to
"GW" and one to "SBC" for the 'Application Type'. If you
configure the parameter to SBC, the device uses the SIP
Interface set to "SBC".
â– [0] GW = (Default) Gateway application
â– [2] SBC = SBC application
'Destination Transport Type'
dst-transport
Defines the transport type for outgoing calls.
â– [-1] = Not configured (default)
- 1070 -
