AudioCodes E-SBC User Manual

CHAPTER68 Configuration Parameters Reference
Mediant 1000 Gateway & E-SBC | User's Manual
Parameter Description
Note:
■ For the parameter to take effect, a
device reset is required.
■ Before setting the parameter, all
SNMPv3 users must be deleted;
otherwise, the parameter setting is
ignored.
■ If the supplied key does not pass
validation of the 12 Hex values input or it
is set with the default value, the engine
ID is generated according to RFC 3411.
SNMP Trap Destination Parameters
(configure system > snmp trap destination)
Note: Up to five SNMP trap managers can be defined.
'SNMP Manager'
[SNMPManagerIsUsed_x]
Determines the validity of the parameters
(IP address and port number) of the
corresponding SNMP Manager used to
receive SNMP traps.
■ [0] (Check box cleared) = Disabled
(default)
■ [1] (Check box selected) = Enabled
'IP Address'
ip-address
[SNMPManagerTableIP_x]
Defines the IP address of the remote host
used as an SNMP Manager. The device
sends SNMP traps to this IP address.
Enter the IP address in dotted-decimal
notation, e.g., 108.10.1.255.
'Trap Port'
port
[SNMPManagerTrapPort_x]
Defines the port number of the remote
SNMP Manager. The device sends SNMP
traps to this port.
The valid SNMP trap port range is 100 to
4000. The default port is 162.
'Trap Enable'
send-trap
[SNMPManagerTrapSendingEnable_x]
Enables the sending of traps to the
corresponding SNMP manager.
■ [0] Disable = Sending is disabled.
■ [1] Enable = (Default) Sending is
enabled.
'Trap User'
trap-user
[SNMPManagerTrapUser_x]
Defines the SNMPv3 USM user or SNMPv2
user to associate with the trap destination.
This determines the trap format,
authentication level, and encryption level.
By default, it is associated with the
SNMPv2 user (SNMP trap community
string).
The valid value is a string.
- 1103 -
