CHAPTER68 Configuration Parameters Reference
Mediant 1000 Gateway & E-SBC | User's Manual
Parameter Description
â– For the Gateway application: The challenge can be
cached per endpoint or per Account.
â– For the SBC application: The challenge can be
cached per Account or per user whose credentials
are configured in the User Information table.
Registrar Parameters
'Enable Registration'
configure voip > sip-
definition proxy-and-
registration > enable-
registration
[IsRegisterNeeded]
Enables the device to register to a Proxy/Registrar
server.
â– [0] Disable = (Default) The device doesn't register
to Proxy/Registrar server.
â– [1] Enable = The device registers to
Proxy/Registrar server when the device is powered
up and at every user-defined interval (configured by
the parameter RegistrationTime).
Note:
â– The parameter is applicable only to the Gateway
application.
â– The device sends a REGISTER request for each
channel or for the entire device (according to the
AuthenticationMode parameter).
'Registrar Name'
configure voip > sip-
definition proxy-and-
registration > registrar-
name
[RegistrarName]
Defines the Registrar domain name. If specified, the
name is used as the Request-URI in REGISTER
messages. If it isn't specified (default), the Registrar IP
address, or Proxy name or IP address is used instead.
The valid range is up to 100 characters.
Note: The parameter is applicable only to the Gateway
application.
'Registrar IP Address'
configure voip > sip-
definition proxy-and-
registration > ip-addrr-
rgstrr
[RegistrarIP]
Defines the IP address (or FQDN) and port number
(optional) of the Registrar server. The IP address is in
dotted-decimal notation, e.g., 201.10.8.1:<5080>.
Note:
â– The parameter is applicable only to the Gateway
application.
â– If not specified, the REGISTER request is sent to
the primary Proxy server.
â– When a port number is specified, DNS
NAPTR/SRV queries aren't performed, even if the
parameter DNSQueryType is set to 1 or 2.
- 1152 -
