CHAPTER68 Configuration Parameters Reference
Mediant 1000 Gateway & E-SBC | User's Manual
Parameter Description
■ [0] Disable (default)
■ [1] Enable
For example, if the incoming INVITE From
header contains "12345" and the destined B-
channel number is 17, then the outgoing
calling party number in the Q.931 Setup
message is set to "17" instead of "12345".
Note:
■ When enabled, this feature is applied
after routing and manipulation on the
source number (i.e., just before sending
to the Tel side).
■ The parameter is applicable only to
digital interfaces.
'Tel2IP Default Redirect Reason'
configure voip > gateway
manipulation settings > tel-to-
ip-dflt-redir-rsn
[Tel2IPDefaultRedirectReason]
Determines the default redirect reason for
Tel-to-IP calls when no redirect reason (or
“unknown”) exists in the received Q931
ISDN Setup message. The device includes
this default redirect reason in the SIP
History-Info header of the outgoing INVITE.
If a redirect reason exists in the received
Setup message, the parameter is ignored
and the device sends the INVITE message
with the reason according to the received
Setup message. If the parameter is not
configured (-1), the outgoing INVITE is sent
with the redirect reason as received in the
Setup message (if none or “unknown”
reason, then without a reason).
■ [-1] Not Configured = (Default)
Received redirect reason is not changed
■ [1] Busy = Call forwarding busy
■ [2] No Reply = Call forwarding no reply
■ [9] DTE Out of Order = Call forwarding
DTE out of order
■ [10] Deflection = Call deflection
■ [15] Systematic/Unconditional = Call
forward unconditional
Note: The parameter is applicable only to
digital interfaces.
'Redirect Number IP-to-Tel'
configure voip > gateway routing
settings > redir-nb-si-2tel
[SetIp2TelRedirectScreeningInd]
Defines the value of the Redirect Number
screening indicator in ISDN Setup
messages.
■ [-1] Not Configured (default)
■ [0] User Provided
■ [1] User Passed
■ [2] User Failed
- 1319 -
