CHAPTER13 Network
Mediant 1000 Gateway & E-SBC | User's Manual
Index Destination Prefix Length Gateway
0 176.85.49.0 24 192.168.0.10
The NTP application is configured (through the ini file) to serve as OAMP applications:
EnableNTPasOAM = 1
Configure Layer-2 QoS mapping in the QoS Mapping table. Packets sent with the configured
DiffServ get the configured VLAN priority:
Index Differentiated Services VLAN Priority
0 46 6
1 40 6
2 26 4
3 10 2
Configure Layer-3 QoS in the QoS Settings table:
● 'Media Premium QoS' - the default DiffServ value is 46
● 'Control Premium QoS' - the default DiffServ value is 24
● 'Gold QoS' - the default DiffServ value is 26
● 'Bronze QoS' - the default DiffServ value is 10
■ IP Network Interfaces and Multiple Default Gateways:
This example includes a different Default Gateway per IP network interface. The Default
Gateway of the OAMP interface is 192.168.0.1 and of the Media and Control is 200.200.85.1.
The configuration in the IP Interfaces table is shown below:
Inde-
x
Name
Applic-
ation Type
Eth-
ernet
Device
Inter-
face
Mode
IP Address
Prefix
Lengt-
h
Default
Gateway
0 Mgmt OAMP 100 IPv4
Manual
192.168.0.2 16 192.168.0.1
1 CntrlMedi
a
Media &
Control
200 IPv4
Manual
200.200.85.1
4
24 200.200.85.
1
Configuring the following static routing rules in the Static Routes table enables OAMP
applications to access peers on subnet 17.17.0.0 through the Default Gateway 192.168.10.1
and Media + Control applications to access peers on subnet 171.79.39.0 through Default
Gateway 200.200.85.10 (which is not the default gateway of the interface).
Index Destination
Prefix
Length
Ethernet Output
Device
Gateway
0 17.17.0.0 16 100 192.168.10.1
1 171.79.39.0 24 200 200.200.85.10
- 104 -
