CHAPTER16 Services
Mediant 1000 Gateway & E-SBC | User's Manual
● You cannot configure overlapping Time Bands.
● If a Time Band is not configured for a specific day and time range, the default
connection cost and default minute cost configured for the Cost Group in the Cost
Groups table is applied.
The following procedure describes how to configure Time Bands per Cost Group through the Web
interface. You can also configure it through ini file [CostGroupTimebands] or CLI (configure
voip > sip-definition least-cost-routing cost-group-time-bands).
➢ To configure a Time Band per Cost Group:
1. Open the Cost Groups table (Setup menu > Signaling & Media tab > SIP Definitions folder
> Least Cost Routing > Cost Groups).
2. Select a Cost Group for which you want to assign Time Bands, and then click the Time Band
link located below the table; the Time Band table for the selected Cost Group appears.
3. Click New; the following dialog box appears:
4. Configure a Time Band according to the parameters described in the table below.
5. Click Apply, and then save your settings to flash memory.
Table 16-17:Time Band Table Description
Parameter Description
'Index'
timeband-index
[CostGroupTimebands_
TimebandIndex]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
'Start Time'
start-time
[CostGroupTimebands_
StartTime]
Defines the day and time of day from when this time band is
applicable. The format is DDD:hh:mm, where:
■ DDD is the day of the week, represented by the first three
letters of the day in upper case (i.e., SUN, MON, TUE, WED,
THU, FRI, or SAT).
■ hh and mm denote the time of day, where hh is the hour (00-23)
and mm the minutes (00-59)
For example, SAT:22:00 denotes Saturday at 10 pm.
- 242 -
