CHAPTER18 Core Entities
Mediant 1000 Gateway & E-SBC | User's Manual
Table 18-3: SRDs table Parameter Descriptions
Parameter Description
General
'Index'
[SRD_Index]
Defines an index for the new table row.
Note: Each row must be configured with a unique
index.
'Name'
name
[SRD_Name]
Defines a descriptive name, which is used when
associating the row in other tables.
The valid value can be a string of up to 40 characters.
Note:
â– The parameter is mandatory.
â– Each row must be configured with a unique name.
â– The parameter value cannot contain a forward
slash (/).
'Sharing Policy'
type
[SRD_SharingPolicy]
Defines the sharing policy of the SRD, which
determines whether the SRD shares its SIP
resources (SIP Interfaces, Proxy Sets, and IP
Groups) with all other SRDs (Shared and Isolated).
â– [0] Shared = (Default) SRD shares its resources
with other SRDs (Isolated and Shared) and calls
can thus be routed between the SRD and other
SRDs.
â– [1] Isolated = SRD does not share its resources
with other SRDs and calls cannot be routed
between the SRD and other Isolated SRDs.
However, calls can be routed between the SRD
and other Shared SRDs.
For more information on SRD Sharing Policy, see
Multiple SRDs for Multi-tenant Deployments.
Note: The parameter is applicable only to the SBC
application.
'SBC Operation Mode'
sbc-operation-mode
[SRD_SBCOperationMode]
Defines the device's operational mode for the SRD.
â– [0] B2BUA = (Default) Device operates as a
back-to-back user agent (B2BUA), changing the
call identifiers and headers between the inbound
and outbound legs.
â– [1] Call Stateful Proxy = Device operates as a
Stateful Proxy, passing the SIP message
transparently between inbound and outbound
legs. In other words, the same SIP dialog
identifiers (tags, Call-Id and CSeq) occur on both
legs (as long as no other configuration disrupts
the CSeq compatibleness).
For more information on B2BUA and Stateful Proxy
modes, see B2BUA and Stateful Proxy Operating
Modes.
Note:
- 323 -
