CHAPTER34 Routing SBC
Mediant 1000 Gateway & E-SBC | User's Manual
Parameter Description
â– The parameter is applicable only if the 'Destination Type'
parameter is configured to IP Group. However, you also need to
specify this parameter if the 'Destination Type' parameter is
configured to Dest Address, Request URI, ENUM, Dial Plan
or LDAP (even though these calls are not sent to the specified
IP Group). For these cases, it allows you to associate other
configuration entities (such as an IP Profile) that are assigned to
the IP Group, with the destination of these calls.
â– The selectable IP Group for the parameter depends on the
assigned Routing Policy (in the 'Routing Policy' parameter in
this table). For more information, see Configuring SBC Routing
Policy Rules.
'Destination SIP
Interface'
dest-sip-
interface-name
[IP2IPRouting_
DestSIPInterfaceNam
e]
Defines the destination SIP Interface to where the call is sent.
By default, no value is defined.
To configure SIP Interfaces, see Configuring SIP Interfaces.
Note:
â– The parameter is applicable only if the 'Destination Type'
parameter is configured to any value other than IP Group. If the
'Destination Type' parameter is configured to IP Group, the
following SIP Interface is used:
✔ Server-type IP Groups: SIP Interface that is assigned to the
Proxy Set associated with the IP Group.
✔ User-type IP Groups: SIP Interface is determined during
user registration with the device.
â– For multi-tenancy, if the assigned Routing Policy is not shared
(i.e., the Routing Policy is associated with an Isolated SRD), the
SIP Interface must be one that is associated with the Routing
Policy or with a shared Routing Policy (i.e., the Routing Policy is
associated with one or more Shared SRDs). If the Routing
Policy is shared, the SIP Interface can be one that is associated
with any SRD or Routing Policy (but it's recommended that it
belong to the same SRD/Routing Policy or to shared
SRD/Routing Policy to avoid "bleeding").
'Destination Address'
dst-address
[IP2IPRouting_
DestAddress]
Defines the destination address to where the call is sent.
The valid value is an IP address in dotted-decimal notation or an
FQDN (domain name, e.g., domain.com).
If ENUM-based routing is used (i.e., the 'Destination Type'
parameter is set to ENUM) the parameter configures the address of
the ENUM service, for example, e164.arpa, e164.customer.net or
NRENum.net. The device sends the ENUM query containing the
destination phone number to an external DNS server, configured in
the IP Interfaces table. The ENUM reply includes a SIP URI
(user@host) which is used as the destination Request-URI in this
routing table.
The valid value is a string of up to 50 characters (IP address or
FQDN). By default, no value is defined.
Note:
- 783 -
