CHAPTER34 Routing SBC
Mediant 1000 Gateway & E-SBC | User's Manual
Parameter Description
Note: For the Random Weight optional value, use the 'Weight' parameter in
the IP Group Set Member table (below) to configure weight value per IP
Group.
'Tags'
tags
[IPGroupSet_
Tags]
Assigns a Dial Plan tag that is used to determine whether the incoming SIP
dialog is sent to IP Groups belonging to this IP Group Set. The parameter is
used when IP-to-IP Routing rules are configured for destination based on tags
(i.e., 'Destination Type' parameter configured to Destination Tag). For more
information on routing based on destination tags, see Using Dial Plan Tags for
Routing Destinations.
The valid value is a string of up to 70 characters. By default, no value is
defined. You can configure the parameter with up to five tags, where each tag
is separated by a semicolon (;). Each tag can have a name and value (e.g.,
Country=Ireland) or only a value (e.g., Ireland). You can also configure
multiple tags with the same name (e.g., Country=Ireland;Country=Scotland).
Note: If the IP Groups belonging to the IP Group Set are also configured with
Dial Plan tags, the Dial Plan tag configured for the parameter takes
precedence. If the same Dial Plan tag is also configured for other IP Groups in
the IP Groups table, the IP Group Set takes precedence and the device sends
the SIP dialog to the IP Group(s) belonging to the IP Group Set.
5. Select the IP Group Set row for which you want to assign IP Groups, and then click the IP
Group Set Member link located below the table; the IP Group Set Member table appears.
6. Click New; the following dialog box appears:
7. Configure IP Group Set members according to the parameters described in the table below.
8. Click Apply, and then save your settings to flash memory.
Table 34-6: IP Group Set Member Table Parameter Descriptions
Parameter Description
'Index'
index
[IPGroupSetMember_
IPGroupSetMemberIndex]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
'IP Group'
ip-group-name
Assigns an IP Group to the IP Group Set.
To configure IP Groups, see Configuring IP Groups.
Note: The IP Group can only be a Server-type or Gateway-type.
- 801 -
