Version 6.6 251 October 2014
Installation & Operation Manual 28. Working with the Media Gateway Boards (TP-6310 and TP-8410)
28.5.3 Desired Redundancy Mode
Desired Redundancy Mode determines the highest level of protection requested by
the user. The Desired Redundancy Mode may be configured for the Redundancy
Group (and thus affect all Media Gateway boards associated with the specific group)
or for each specific Media Gateway board.
 To configure the desired Redundancy mode for a Redundancy group:
1. Click
to access the Media Gateway status screen.
2. In the Navigation pane, select Redundancy
Redundancy Groups; the
Redundancy Groups list is displayed.
3. Select a specific row and then in the configuration pane, click Redundancy
Group Settings; the Redundancy Group Settings screen is displayed.
4. Set Redundancy Mode parameter to Not Protected, Hot or Warm.
 To configure desired Redundancy mode for a specific Media Gateway board:
1. Click
to access the Media Gateway status screen.
2. Select the specific Media Gateway board.
3. In the Navigation pane, select Redundancy and then in the configuration pane,
click Redundancy Settings; the Redundancy Settings screen is displayed.
4. Configure Desired HA Mode parameter as follows:
a. To use Redundancy Group configuration, set Desired HA Mode parameter
to Use RG Configuration
b. To configure Desired HA Mode for a specific Media Gateway board, set
Desired HA Mode parameter to Not Protected, Hot or Warm.
