Installation & Operation Manual 504 Document # LTRT-92224
Mediant 8000
 To configure Alias Point Codes:
1. Configure the MTP3/M3UA application, as described in 'Configuring the
MTP3/M3UA Application' on page 485.
2. Click
to access the Media Gateway Status screen.
3. In the Navigation pane, select PSTN and then select the corresponding SS7.
4. In the Navigation pane, select SS7 Alias Point Code; the SS7 Alias Point Code
status screen is displayed.
5. Use the
or buttons to add or remove entries.
6. Select a specific row and then in the configuration pane, click SS7 Alias Point
Code Settings; the SS7 Alias Point Code Settings screen is displayed.
7. Configure the “alias” point code value. Use the same syntax as for Originating
PC parameter in SS7 Node.
8. For each defined Alias Point Code, create and configure an M3UA Routing
Context that defines routing rules for M3UA messages based on their source
point codes and service indicators. Use the same procedure as described in
'Configuring the MTP3/M3UA Application' on page 485.
9. Activate the new configuration by restarting the corresponding Media Gateway
board via Lock and consequent Unlock maintenance actions (for redundant
configurations, you must lock both Media Gateway boards that are associated
with the specific MTP3 Group).
38.6.5 Configuring the M2TN Application
The following entities are relevant to the M2TN (SG side) application:

SS7 Data Link – represents the MTP2 signaling link connected to the PSTN
network.

UAL Group – represents the SCTP association between the Media Gateway
boards.

UAL Interface – represents the single M2UA link transferred between the Media
Gateway boards via the IP network.

MTP2Profile – defines the MTP2 signaling link timers and configuration.
To configure a Media Gateway on the Remote PSTN side, see Section 'Configuring
the M2UA (SG Side) Application' on page 476. Define one UAL Group for SCTP
association between Media Gateway boards.
 To configure Media Gateway on the Central TDM switch side:
1. Create and configure tunneling SS7 Data Links for each signaling link
connected to the central TDM switch.
a. Click
to access the Media Gateway status screen.
b. Select the desired Media Gateway board.
c. In the Navigation pane, select PSTN
SS7 SS7 Data Links; the SS7
Data Links list is displayed.
