AudioCodes Mediant 8000 User Manual

Installation & Operation Manual 672 Document # LTRT-92224
Mediant 8000
Table 41-11: Telephone to IP / Outbound Routing Table "Matching Rules"
Parameter Name Type
Provisioning
Type
Description
Source IP Group Integer
-1 (Not Defined) or
1-32
Instant For Tel-to-IP calls, set this parameter to -1
(Not Defined).
For IP-to-IP calls, specify the IP Group
from where the call originated. Typically,
the IP Group of an incoming INVITE is
determined/classified using the ‘IP to Tel /
Inbound Routing’ table. To denote any IP
Group, set to -1 (Not Defined)
If the Source IP Group has a Serving IP
Group, then all calls originating from this
Source IP Group are sent to the Serving
IP Group. In this scenario, this table is
used only if in the SIP Routing Settings
screen, the Prefer Routing Table
parameter is set to Enabled.
Source Host
Prefix
String
Up to 50 chars.
Instant For Tel-to-IP calls, leave this field empty.
For IP-to-IP calls, specify the prefix of the
SIP URI host name in the From header of
the incoming SIP INVITE message.
To denote any source host leave the field
empty or use asterisk (*) symbol.
Destination Host
Prefix
String
Up to 50 chars.
Instant For Tel-to-IP calls, leave this field empty.
For IP-to-IP calls, specify the request SIP
URI host name prefix of the incoming SIP
INVITE message.
To denote any destination host leave the
field empty or use asterisk (*) symbol.
Source Trunk
Group
Integer
0 (Not Defined) or
1-100
Instant For Tel-to-IP calls, specify the source
Trunk Group. To denote any Trunk Group,
set to -1 (Not Defined).
For IP-to-IP calls, set to -1 (Not Defined).
Dest Phone
Prefix
String
Up to 19 chars.
Instant Represents a called telephone number
prefix. An asterisk (*) represents all
numbers.
Source Phone
Prefix
String
Up to 19 chars.
Instant Represents a calling telephone number
prefix. An asterisk (*) represents all
numbers.
