Installation & Operation Manual 892 Document # LTRT-92224
Mediant 8000
modify OAMTagID=10
add moVlanTag#1modify moVlanTag#1 VLANTagID=11
add moVlanTag#2
modify moVlanTag#2 VLANTagID=12
B.2.6 Subnets and Network Profiles Settings
In the Media Gateway CLI, specify the following commands to configure the
corresponding Subnets and Network Profiles:
add moSubnet#2
modify moSubnet#2 SubnetIP=10.77.11.0
modify moSubnet#2 SubnetPrefixBitsLength=24
modify moSubnet#2 DefaultGW=10.77.11.1
modify moSubnet#2 VLANTagID=11
add moSubnet#3
modify moSubnet#3 SubnetIP=10.77.12.0
modify moSubnet#3 SubnetPrefixBitsLength=24
modify moSubnet#3 DefaultGW=10.77.12.1
modify moSubnet#3 VLANTagID=12
add moNetworkProfile#1/moNetworkSubnet#2
modify moNetworkProfile#1/moNetworkSubnet#2 SubnetIndex=2
add moNetworkProfile#1/moNetworkSubnet#3
modify moNetworkProfile#1/moNetworkSubnet#3 SubnetIndex=3
B.2.7 Media Gateway Board’s IP Addresses
In the Media Gateway CLI, specify the following commands to set the IP addresses of
Media Gateway boards:
modify moBoard#7/moBoardIPAddress#1=10.77.10.100
modify moBoard#7/moBoardIPAddress#2=10.77.11.100
modify moBoard#7/moBoardIPAddress#3=10.77.12.100
