Version 6.6 855 October 2014
Installation & Operation Manual 49. Collecting Advanced Media Gateway Board Logs
49.5 Collecting the Media Gateway Board's INI File
The INI file contains the configuration data of the Media Gateway board. It may be
used together with Advanced Media Gateway board logs to perform advanced
troubleshooting.
 To collect the INI File from the Media Gateway board:
1. Click
to access the Media Gateway status screen.
2. Select the desired Media Gateway board.
3. Right-click the selected Media Gateway board and from the pop-up menu, select
Maintenance
Save INI File; the Save INI File dialog is displayed.
4. Choose a location on your PC or on the file server to save the INI file using one
of the following options:
• INI file – includes only those parameters with changed values (not including
those with default values).
• Complete INI file– includes all parameters (including those with default
values).
