Table 38-7: SS7 Data Link Properties - Data Link General Info Tab
Parameter Name Type
Provisioning
Type
Description
SS7 Link Name String
Up to 20 chars.
Offline_create The textual, user-defined name assigned to
the SS7 Data Link, enabling it to be identified
intuitively and easily.
Layer 2 Type Enum
Mtp2, M2ua,
Saal
Offline_create Defines the Layer 2 entity as implemented by
SS7 Data Link.
 For the M2UA (SG side) and MTP3/M3UA
applications, define the Layer 2 type as
MTP2.
 For the M2UA (MGC side) application,
define the Layer 2 type as M2UA.
 For the broadband SS7 (UMTS)
application, define the Layer 2 type as
SAAL.
Layer 2 Variant Enum
Itu, Ansi
Online Defines the national variant of the Layer 2
protocol used by SS7 Data Link.
The value must match the configuration on
the remote PSTN side.
Layer 3 Type Enum
M2ua, Mtp3,
M2tn
Offline_create Defines the Layer 3 entity from/to which the
SS7 Data Link transfers the data.
 For the M2UA (SG side) application,
define the Layer 3 type as M2UA
 For MTP3/M3UA, M2UA (MGC side) and
broadband SS7 (UMTS) applications,
define the Layer 3 type as MTP3.
 For the M2TN tunneling application, define
the Layer 3 type as M2TN
Trace Level Integer
0-1
Instant The trace-level indication for the SS7 Link
Layer protocols.
