AudioCodes Mediant 8000 User Manual

Version 6.6 83 October 2014
Installation & Operation Manual 13. Ethernet Switch Board
13.2.3 ES-2 Physical Slots to Ethernet Port Mapping
Use the following table to determine which Mediant 8000 physical slot is connected to
the specific ethernet switch port.
Table
13-5: ES-2 Physical Front Slots to Ethernet Port Mapping
Chassis Slot
Number
Slot 9 Ethernet
Switch Port
Slot 19 Ethernet
Switch Port
Dedicated to Board Type
1 13 13 SC
2 14 14 SC
3 - - N/A
4 15 15 Redundant TP-8410
5 - - N/A
6 - - N/A
7 16 16 TP-6310 or TP-8410
8 17 17 TP-6310
9 - 11,12 Ethernet Switch
10 - - N/A
11 18 18 TP-6310 or TP-8410
12 19 19 TP-6310 or TP-8410
13 20 20 TP-6310 or TP-8410
14 21 21 TP-6310 or TP-8410
15 22 22 TP-6310 or TP-8410
16 23 23 TP-6310
17 24 24 Redundant TP-6310
18 - - N/A
19 11,12 - Ethernet Switch
