AudioCodes Mediant 8000 User Manual

Version 6.6 635 October 2014
Installation & Operation Manual 40. General SIP Configuration
40.13.2 Configuring the Cost Group Table
The following table has a child table Time Bands table. The Cost Group table can’t be
removed until the Time Bands table is removed. When the Cost Group table is locked,
all associated Time Bands tables are also locked..
 To configure the Cost Group Table:
1. Click
to access the Media Gateway status screen.
2. Select the desired SIP board.
3. In the Navigation Pane, select SIP
SIP General Least Cost Routing Cost
Group; the Cost Group list is displayed.
4. Use the
or buttons to add or remove entries. Note – only one can be
added.
5. Select a specific row and in the Configuration pane, click SIP Cost Group Group
Frame; the SIP Cost Group screen is displayed.
6. Configure Cost Group parameters according to the table Cost Group Parameters'
below.
7. Click the Maintenance icon
and select Unlock to activate the configuration.
Cost Group Parameters
Parameter
Name
Type
Provisioning
Type
Description
Cost Group
Name
String
up to 30 chars
Instant Defines An Unique Name For The Cost
Group.
Default Connect
Cost
Integer
0- 3000
Instant Defines The Call Connection Cost (added As
A Fixed Charge To The Call) For A Call
Outside The Time Bands.
Default Time
Cost
Integer
0- 3000
Instant Defines the call charge per minute for a call
outside the time bands.
