Version 6.6 87 October 2014
Installation & Operation Manual 14. Board Assembly Order
14 Board Assembly Order
For a system configuration with less than the full complement of Media Gateway
boards, the board assembly should follow the tables below.
Note : The Redundant Media Gateway board must be accompanied with a redundant
RTM module.
Table 14-1: Board Assembly Order
Slot # Front Board Rear Board
Slot 1 SC SA/RTM
Slot 2 SC SA/RTM
Slot 3 Blank Panel Blank Panel
Slot 4 TP-8410 Redundant board 8410/RTM/Redundant
Slot 5 Blank Panel Blank Panel
Slot 6 Blank Panel Blank Panel
Slot 7 TP-6310 #8 or TP-8410 #6 6310/RTM or 8410/RTM
Slot 8 TP-6310 #7 6310/RTM
Slot 9 ES/6600 or ES-2 ES/6600/RTM or ES-2/RTM
Slot 10 Blank Panel Blank Panel
Slot 11 TP-6310 #6 or TP-8410 #5 6310/RTM or 8410/RTM
Slot 12 TP-6310 #5 or TP-8410 #4 6310/RTM or 8410/RTM
Slot 13 TP-6310 #4 or TP-8410 #3 6310/RTM or 8410/RTM
Slot 14 TP-6310 #3 or TP-8410 #2 6310/RTM or 8410/RTM
Slot 15 TP-6310 #2 or TP-8410 #1 6310/RTM or 8410/RTM
Slot 16 TP-6310 #1 6310/RTM
Slot 17 TP-6310 Redundant board 6310/RTM/Redundant
Slot 18 Blank Panel Blank Panel
Slot 19 ES/6600 or ES-2 ES/6600/RTM or ES-2/RTM
Caution
For continuous compliance with EMS standards, unoccupied slots should be
covered with either blank covers with air baffles or blank covers.
