AudioCodes Mediant 8000 User Manual

Version 6.6 551 October 2014
Installation & Operation Manual 40. General SIP Configuration
Parameter
Name
Type
Provisioning
Type
Description
Use Routing
Table For Host
Names
Enum
Disable, Enable
Instant Enables use of the internal Tel to IP routing
table to obtain the URI Host name and
(optionally) an IP profile (per call), even if
Proxy server is used.
Redundant
Routing Mode
Enum
NoRedundant,
RoutingTable,
RedundantProxy
Instant Defines the type of redundant routing
mechanism to implement when a call can't
be completed using the main route.
ReRouting Mode Enum
Standard, Proxy,
RoutingTable
Instant Define the Gateway action as a result of
receiving 3xx or Transfer response:
 Standard – send Invite according to
standard behavior
 Proxy – send IINVITE to Proxy.
RoutingTable – send INVITE according to
Routing Table.
Use Routing
Table when
Proxy Fails
Enum
No, Yes
Instant Defines SIP messages routing rules when
SIP Proxy server fails:
 No – Gateway fallback is not used.
 Yes – Internal Tel to IP Routing table is
used when Proxy servers are not
available.
When the gateway falls back to the internal
Tel to IP Routing table, the gateway
continues scanning for a Proxy. When the
gateway finds an active Proxy, it switches
from internal routing back to Proxy routing.
Send Invite To
Proxy
Enum
Disable, Enable
Instant Defines routing rules for SIP 'INVITE'
messages:
 Disable – INVITE messages, generated
as a result of Transfer or Redirect, are
sent directly to the URL (according to
the refer-to header in the REFER
message or contact header in 30x
response).
 Enable – all INVITE messages,
including those generated as a result of
Transfer or Redirect are sent to Proxy.
Note: Applicable only if Proxy server is
used and Always Send to Proxy is
Disabled.
