ATM-TRK (Circuit Emulation Service Circuit Pack)
Issue 4 May 2002
10-233 555-233-123
4. Perform ATM loopback tests on the near-end ATM-TRK circuit pack
and on the far-end circuit pack or ATM switch.
5. Check capacity and peak bandwidth consumption for the ATM span.
h. Error Type 771: the ATM switch is sending cells with unknown Virtual
Path-Identifier (VPI) and Virtual Channel-Identifier (VCI) addresses.
1. Make sure that the ATM-TRK circuit-pack address is administered
identically on the ATM switch and the Avaya DEFINITY Server.
i. Error Type 1281: Board major signals error (loss of high-level signal). The
far-end has detected a major problem in transmissions originating from the
ATM-TRK circuit pack. The possible Aux Data values for this software
counter are listed in Table 10-93.
If Then
The ATM-TRK circuit pack
fails the loopback test.
The problem is in the ATM-TRK circuit
pack. Replace the circuit pack.
The far-end circuit pack or
ATM switch fails the
loopback test.
The problem is in the far-end circuit pack
or ATM switch. Consult the circuit-pack or
ATM switch documentation for advice.
The equipment at each end
of the ATM span passes
the loopback test
The problem is somewhere in the ATM
span. Lack of bandwidth can be forcing
an intermediate ATM switch to drop cells.
If Then
The capacity of the span is
inadequate or bandwidth
consumption is too high.
Reduce traffic on the Avaya DEFINITY
Server to ensure that it is using no more
that its subscribed bandwidth.
Table 10-93. Error type 1281 Aux Data and repair procedures
Aux
Data
Alarm
Description Repair procedure
15 SYSCLOCK failed The board is not locked to the TDM backplane clock signal. This is
probably due to a Tone Clock problem.
Check for TDM-BUS or TONE-BD errors in the Error Log.
If no other problems are present, reset the circuit pack (reset board
UUCSS)
Continued on next page
