DATA-BD (Data Channel NetPkt Circuit Pack)
Issue 4 May 2002
10-481 555-233-123
Error Log Entries and Test to Clear Values
Notes:
a. Error Type 1: DATA-BD portion of the TN2401/TN794 NetPkt or TN777B
Netcon circuit pack not functioning.
Cannot reset TN2401/TN794 NetPkt or TN777B Netcon circuit pack with
usual command (reset board PCSS). Use Data Channel Reset Test
(#107) in the Long Test Sequence for the DATA-CHLs to reset.
1. Determine how many Data Channels (DATA-CHLs) are
administered (list data).
NOTE:
A Data Channel (DATA-CHL) is identified by a “type” value of
“netcon.”
2. Administer a DATA-CHL as necessary (add data-module [
ext |
next]).
3. Select a Data Channel (DATA-CHL) from the list (list data).
Table 10-174. Data Channel Processor Circuit Pack Error Log entries
Error
Type
Aux
Data Associated Test
Alarm
Level
On/Off
Board Test to Clear Value
0
1
1 Run the Short Test Sequence first. If all tests pass, run the Long Test Sequence. Refer to the
appropriate test description and follow the recommended procedures.
0 Any Any Any test data-module ext sh r 1
1 (a) 0 Data Channel
Reset Test (#107)
MINOR ON test data-module ext l
23 (b) 0 None WNG OFF
257 Any Control Channel
Test (#52)
MINOR ON test network-control [a | b] sh r
20
257 (c) 0 None
513 (d) Any None
769 (e) 4358 None
1025 (f) 4363 NPE Audit Test
(#50)
test network-control [a | b] sh
1538 (g) Data Channel
Reset Test (#107)
MINOR ON test data-module ext l
3840 (h) Any None
3999(i) Any None
Continued on next page
