Maintenance Object Repair Procedures
555-233-123
10-818 Issue 4 May 2002
Hardware Error Log Entries and Test to Clear
Val ues
System Technician-Demanded Tests: Descriptions
and Error Codes
Investigate tests in the order presented when inspecting errors in the system. By
clearing error codes associated with the Battery & Battery Charger Query Test,
you may also clear errors generated from other tests in the testing sequence.
Table 10-298. Hardware Error Log Entries and Test to Clear Values
Error
Type
Aux
Data Associated Test
Alarm
Level
On/Off
Board Test to Clear Value
0
1
1 Run the Short Test Sequence. If all tests pass, run the Long Test Sequence.
0 Any Any Any test environment UU r2 or 6
1 or 5 Any External Device
Alarm Test (#120)
MAJOR
MINOR
2
2 One port generates a MAJOR alarm; the other port generates a MINOR alarm.
OFF test environment UU r 2 or 6
Multicarrier Cabinet Tests
Order of Investigation
Short Test
Sequence
Long Test
Sequence D/ND
1
1 D = Destructive; ND = Nondestructive
Battery & Battery Charger Query Test (#5) (a) X X ND
AC Power Query Test (#78) (b) X X ND
OLS Query Test (Carrier E) (#127) (c) X X ND
OLS Query Test (Carrier D) (#127) (c) X X ND
OLS Query Test (Carrier A) (#127) (c) X X ND
OLS Query Test (Carrier B) (#127) (c) X X ND
OLS Query Test (Carrier C) (#127) (c) X X ND
Emergency Transfer Query Test (#124) (d) X X ND
Cabinet Sensors Query Test (#122) (e) X X ND
External Device Alarm Test (MAJOR port) (#120) X X ND
External Device Alarm Test (MINOR port) (#120) X X ND
Analog Ring Generator Initialization Test (#117) (f) X X ND
Analog Ring Generator Query Test (#118) (f) X X ND
Continued on next page
