MAPD-BD (MAPD Interface Circuit Pack TN802)
Issue 4 May 2002
10-1051555-233-123
Replacing the hard disk
The TN802 hard drive (Note 5 in Figure 10-67 on page 10-1049) is
field-replaceable.
Table 10-381. Replacing the TN802 hard drive
Step Description Comments
1. Shut down NT Shut down Windows NT by either method described in the
‘‘Shutting down NT on the TN802’’ section.
2. Remove the
circuit pack
Unlatch the circuit pack and remove it from the carrier.
3. Remove the hard
drive
Remove the 2 screws and lift the hard drive out of its
mounting bracket.
4. Replace the hard
drive
Position the new hard drive in the mounting bracket and
replace the 2 screws (Step 3).
5. Replace the
circuit pack
Slide the circuit pack into the slot and lock the latching
lever.
6. Wait for
initialization
Wait for
■ the circuit pack to reseat (faceplate LEDs light then go
out
■ Windows NT boots (PC BOOT displays on the
faceplate LCD)
■ IP Trunk application to run (IP TRK # displays on the
faceplate LCD)
Continued on next page
