Maintenance Object Repair Procedures
555-233-123
10-1070 Issue 4 May 2002
Error Log Entries and Test to Clear Values
Notes:
a. Error Type 1 - indicates that the circuit pack has totally stopped functioning
or is not fully administered. The alarm is logged about 15 minutes after the
circuit pack has been removed or 11-minutes after the
SAKI Test (#53) fails.
To be fully administered, a MedPro circuit pack must meet all of these 4
conditions:
1. Have an entry in the circuit pack form (change circuit pack)
2. Have the MedPro IP address administered (change node-names)
3. Be enabled (change ip-interface)
Table 10-397. DS1 Interface Circuit Pack Maintenance Error Log Entries
Error
Type
Aux
Data Associated Test
Alarm
Level
On/Off
Board Test to Clear Value
0
1
1 Run the Short Test Sequence first. If all tests pass, run the Long Test Sequence. Refer to the
appropriate test description and follow the recommended procedures.
0 Any Any Any test board UUCSS
1(a) 0 Circuit pack removed or SAKI
Test (#53)
MIN/WRN
2
2 If ports are assigned to the circuit pack, then a minor alarm is raised. If no ports are assigned to the
circuit pack, then a warning alarm is raised. The alarm is raised after the circuit pack has been
missing for a period of 15 minutes. Warning alarms are also raised against any ports administered
on the circuit pack.
ON
18(b) 0 busyout board UUCSS WARNING OFF release board UUCSS
23(c) 0 WARNING OFF add ds1 UUCSS
125(d) None None MIN/WRN
3
3 Minor alarms on this MO may be downgraded to warning alarms based on values set in the set
options command.
ON
257(e) 65535 Control Channel Loop Test
(#52)
MINOR ON test board UUCSS l r 2
1538(f) Any Hyper activity MIN/WRN
3
ON
1793 Any NIC Loss Of Signal MIN/WRN
3
test board UUCSS l r 2
2049(g) Any NT PC Failure MIN/WRN
3
reset board UUCSS
2305 Any IP Address Inconsistency test board UUCSS l r 2
2561 Any Ping Error MIN/WRN
3
test board UUCSS l r 5
3841(h) 4358 Log Only
3999(i) Any None
