Routine Maintenance Procedures
555-233-123
5-82 Issue 4 May 2002
Screen 5-20. A500 screen output for show sys interfaces command
■ For each administered port used by a DEFINITY port network, the
Admin Status should be up (use admin up).
■ Oper Status is not pertinent to administration of the A500 and is
discussed in a later section.
■ State should be present, indicating that A500 port board
insertion was successful. If State is invalid, then the A500
believes that the corresponding port board slot is empty or the port
board is not recognized.
It may be necessary to re-administer the A500 port boards. Refer to
the Cajun A500 Quick Reference for further information.
■ If Admin Status or State is incorrect, the links will not come up
between the PPN and the EPN.
Device Oper Admin State Type
Status Status
_________________________________________________________________
A1.1 up up present STS_3c (MultiMode)
A1.2 up up present STS_3c (MultiMode)
A1.3 down down present STS_3c (MultiMode)
A1.4 down down present STS_3c (MultiMode)
A1.5 down down present STS_3c (MultiMode)
A1.6 down down present STS_3c (MultiMode)
A1.7 down down present STS_3c (MultiMode)
A1.8 down down present STS_3c (MultiMode)
A2.1 down down present STS_3c (MultiMode)
A2.2 down down present STS_3c (MultiMode)
A2.3 down down present STS_3c (MultiMode)
A2.4 down down present STS_3c (MultiMode)
A2.5 down down present STS_3c (MultiMode)
A2.6 down down present STS_3c (MultiMode)
A2.7 down down present STS_3c (MultiMode)
A2.8 down down present STS_3c (MultiMode)
A3.1 down down invalid STS_3c (MultiMode)
A3.2 down down invalid STS_3c (MultiMode)
A3.3 down down invalid STS_3c (MultiMode)
A3.4 down down invalid STS_3c (MultiMode)
A3.5 down down invalid STS_3c (MultiMode)
A3.6 down down invalid STS_3c (MultiMode)
A3.7 down down invalid STS_3c (MultiMode)
A3.8 down down invalid STS_3c (MultiMode)
A4.1 down down invalid STS_3c (MultiMode)
A4.2 down down invalid STS_3c (MultiMode)
A4.3 down down invalid STS_3c (MultiMode)
A4.4 down down invalid STS_3c (MultiMode)
A4.5 down down invalid STS_3c (MultiMode)
A4.6 down down invalid STS_3c (MultiMode)
A4.7 down down invalid STS_3c (MultiMode)
A4.8 down down invalid STS_3c (MultiMode)
Self up up present PROPVIRTUAL
Self up up present SAR
E1.1 up up present TenBaseT
