Maintenance Object Repair Procedures
555-233-123
10-1086 Issue 4 May 2002
ANY FAIL The test did not detect the test tone through the looparound
connection.
1. Test the tone-clock in the port network that contains
the media processor under test.
2. If the tone-clock is healthy, test the media processor
board again.
3. If the test continues to fail, replace the media
processor board.
PASS The board is functioning properly.
0NO
BOARD
No board was detected by the test.
1. Resolve either wrong board (Error 125) or no board
(Error 131) issues, if applicable.
2. Check that the board is properly translated and
inserted. If so, check for hyperactivity (Error 1538). If
hyperactive, use the reset board UUCSS command.
3. Run the test again. If it fails, the NCE chip on board
may be bad. Replace the board and retest.
Table 10-408. TDM NIC Looparound Test (#1380) — Continued
Error
Code
Test
Result Description/Recommendation
Continued on next page
