Routine Maintenance Procedures
555-233-123
5-84 Issue 4 May 2002
Screen 5-22. List configuration carrier 2a screen
■ The TN230X board should be shown in the correct slot.
■ Fields should have values as indicated below:
4. If the TN230X is inserted and shows a vintage number, enter test board
cabinetcarrierslot for this board on the DEFINITY SAT, as shown in
Screen 5-23 (1b02) and Screen 5-24 (2a01).
Screen 5-23. Screen output for the test board 1b02 command
Field Value
Board Type ATM PNC EI
Vintage The TN230X vintage. If Vintage is no board, then
either the board is in the incorrect slot or board insertion
was not completed correctly.
list configuration carrier 2a
SYSTEM CONFIGURATION
Board Assigned Ports
Number Board Type Code Vintage u=unassigned t=tti p=psa
02A01 ATM PNC EI TN2305 000001
02A09 DS1 INTERFACE TN767E 000004 u u u u u u u u
u u u u u u u u
u u u u u u u u
02A10 DIGITAL LINE TN754B 000016 u u u u u u u u
02A11 ANALOG LINE TN746B 000010 01 u u u u u u u
u u u u u u u u
02A17 DIGITAL LINE TN754C 000002 u u u u u u u u
test board 1b02
TEST RESULTS
Port Maintenance Name Alt. Name Test No. Result Error Code
01B02 ATM-EI 316 PASS
01B02 ATM-EI 598 PASS
01B02 ATM-EI 1258 PASS
01B02 ATM-EI 241 PASS
01B02 ATM-EI 304 PASS
01B02 ATM-EI 1259 PASS
