M/T-ANL (Maintenance/Test Analog Port)
Issue 4 May 2002
10-1143555-233-123
Analog Port Sanity Test (#963)
This test verifies that the port circuitry involved in the analog trunk testing on the
Maintenance/Test Analog Port is functioning properly.
This test will abort if an ATMS Test Call is in progress on the Maintenance/Test
Analog Port when the test is requested.
Table 10-432. TEST #963 Analog Port Sanity Test
Error
Code Test Result Description/Recommendation
2000 ABORT Response to the test request was not received within the
allowable time period.
2100 ABORT System resources required to run this test are not
available.
2500 ABORT An internal operation failed; the test could not be
completed.
1. Retry the command at 1-minute intervals a maximum
of 3 times.
50 FAIL The switch was unable to communicate with the port
circuitry used for analog trunk testing.
1. Reset the circuit pack via the busyout board PCSS,
reset board PCSS, release board PCSS command
sequence.
2. Test the port again via the test port PCSS01 l
command.
3. If the test fails again, replace the circuit pack.
PASS The Maintenance/Test Analog Port analog trunk testing
capability is operating correctly.
Continued on next page
