RING-GEN (Analog Ring Generator)
Issue 4 May 2002
10-1463555-233-123
Notes
a. Refer to POWER (Battery & Battery Charger) Maintenance documentation
for a description of this test.
b. Refer to AC-POWER (AC Power) Maintenance documentation for a
description of this test.
c. Refer to CARR-POW (Carrier Port Power Unit) for AC- and DC-Powered
Systems Maintenance documentation for a description of this test.
d. Refer to EMG-XFER (Emergency Transfer) Maintenance documentation
for a description of this test.
e. Refer to CABINET (Cabinet Sensors) Maintenance documentation for a
description of this test.
f. Refer to EXT-DEV (External Alarm) Maintenance documentation for a
description of this test.
Notes:
a. Refer to DC-POWER (Power) Maintenance documentation for a
description of this test.
b. Refer to EMG-XFER (Emergency Transfer) Maintenance documentation
for a description of this test.
c. Refer to EXT-DEV (External Alarm) Maintenance documentation for a
description of this test.
Analog Ring Generator Initialization Test (#117)
The TN768, or TN780 will report an error to the system software if the ringing
voltage falls to low (only if system software has made a request to the TN768, or
TN780 to monitor the voltage). The Analog Ring Generator Initialization Test
sends a request to the TN768, or TN780. If there are redundant tone/clock circuit
packs in the port network, then the request is sent only to the active tone/clock.
Single-Carrier Cabinet
Order of Investigation
Short Test
Sequence
Long Test
Sequence
D/
ND
1
1 D = Destructive; ND = Nondestructive
Analog Ring Generator Initialization Test (#117) X X ND
Analog Ring Generator Query Test (#118) X X ND
Single-Carrier Power Query Test (#79) (a) X X ND
Emergency Transfer Query Test (#124) (b) X X ND
External Alarm Lead Query Test (#120) (c) X X ND
