Maintenance Object Repair Procedures
555-233-123
10-1496 Issue 4 May 2002
Error Log Entries and Test to Clear Values
System Technician-Demanded Tests: Descriptions
and Error Codes
Always investigate tests in the order presented in the table below. By clearing
error codes associated with the Shadow Link Test, for example, you may also
clear errors generated from other tests in the testing sequence.
The Short and Long Test Sequences for Memory Shadowing Link are identical.
Only one test (Test #318) tests the Memory Shadowing Link.
Table 10-571. Standby SPE Error Log Entries
Error
Type
Aux
Data Associated Test
Alarm
Level
On/Off
Board Test to Clear Value
0
1
1 Run the Short Test Sequence first. If all tests pass, run the Long Test Sequence. Refer to the
appropriate test description and follow the recommended procedures.
0 Any Any Any test shadow-link
2047 Shadow Link Test (#318) MAJOR OFF test shadow-link
2048 Shadow Link Test (#318) MAJOR OFF test shadow-link
2049 Shadow Link Test (#318) MAJOR OFF test shadow-link
2050 Shadow Link Test (#318) MAJOR OFF test shadow-link
Order of Investigation
Short Test
Sequence
Long Test
Sequence D/ND
1
1 D = Destructive; ND = Nondestructive
Shadow Link Test (#318) X X ND
