TONE-PT (Tone Generator)
Issue 4 May 2002
10-1809 555-233-123
1022 ABORT [G3r V2] Tone detection for the system is administered as
wide broadband (tone detection mode 5), and the Tone
Detector used for this test was not a TN420C or TN2182 (the
only circuit packs with this capability). GPTD ports on other
types of Tone Detector circuit packs are taken out of service
since they cannot provide the administered function.
1. Change the tone-detection mode administered on the
system-parameters country-options form
Or
2. Remove all non-TN420C and non-TN2182 circuit packs
from the system.
2000 ABORT Response to the test request was not received within the
allowable time period. System resources required for this test
are not available.
1. Retry the command at 1-minute intervals a maximum of 5
times.
2. If the test continues to abort, follow normal escalation
procedures.
2100 ABORT System resources required for this test are not available.
1. Retry the command at 1-minute intervals a maximum of 5
times.
2. If the test continues to abort, follow normal escalation
procedures.
1 (a) FAIL DTMF generation failed for the active tone generator.
105 (a) FAIL Generation of 440-Hz failed.
109 (a) FAIL Generation of 2225-Hz failed.
110 (b) FAIL Generation of 404-Hz level invalid.
111 (b) FAIL Generation of 1004-Hz low level invalid.
112 (b) FAIL Generation of 1004-Hz high level invalid.
113 (b) FAIL Generation of 2804-Hz level invalid.
115 (b,c) FAIL Generation of digital count sequence invalid.
120 (a) FAIL Generation of quiet tone failed.
1044 (a) FAIL DTMF generation failed to generate Digit 1 for the standby
tone generator.
Table 10-657. TEST #40 Tone Generator Transmission Test — Continued
Error
Code
Te s t
Result Description/Recommendation
Continued on next page
