TONE-PT (Tone Generator)
Issue 4 May 2002
10-1813 555-233-123
Tone Generator Crosstalk Test (#90)
This test checks the ability of the Tone Generator to talk on a specific time slot.
The tone generator is told to talk on a specific time slot. The other idle time slots
are checked to make sure the Tone Generator put the tone on only the specified
time slot.
Table 10-659. TEST #90 Tone Generator Crosstalk Test
Error
Code
Te s t
Result Description/Recommendation
None ABORT Internal System Error
1. Retry the command at 1-minute intervals a maximum of 5
times.
2. If the test continues to abort, follow normal escalation
procedures.
1001 ABORT The system was not able to put the tone generation facility in the
appropriate mode to test it.
1002 ABORT The system could not allocate time slots for the test connection.
This can happen when the system is heavily loaded. If the system
is not heavily loaded, then test the TDM-BUS via test tdm
port-network PN# . Refer to TDM-BUS section for details.
2000 ABORT Response to the test request was not received within the allowable
time period.
2100 ABORT Could not allocate the necessary system resources to run this test.
1. Retry the command at 1-minute intervals a maximum of 5
times.
2. If the test continues to abort, follow normal escalation
procedures.
FAIL The Tone Generator could be defective. In a Port Network with
more than one Tone-Clock circuit pack, the system will attempt to
move the tone generation function to the alternate one.
1. Test the Tone-Clock circuit pack again via test tone-clock PC.
2. If the test fails again, look at the Hardware Error Log for Tone
Detector circuit pack errors.
3. If there are Tone Detector circuit pack errors, refer to Tone
Detector Maintenance documentation (DTMR-PT, GPTD-PT,
CLAS-PT, ETR-PT) to resolve these errors first.
4. If there are no Tone Detector circuit pack errors, then the
Tone-Clock circuit pack should be replaced. See ‘‘How to
Replace a Tone-Clock Circuit Pack’’.
PASS The tone generation facility is able to put tones out.
Continued on next page
