Maintenance Object Repair Procedures
555-233-123
10-1834 Issue 4 May 2002
H600-513 cable pinout
Table 10-664 shows the pinout for the H600-513 cable assembly:
Administration
The TN2242 circuit pack requires board-level translation data. Before
administering any ports on the circuit pack, administer the following forms:
■ Circuit pack (change circuit pack)
■ DS1 (add ds1)
■ Trunk group (add trunk group n)
Table 10-665 outlines the trunk group administration parameters that are
required for this interface to operate successfully in Japan.
Table 10-664. H600-513 cable assembly pinout
TN2242 TDM
50-pin
connection pin
number Color Lead Designation Color
15-pin
connection
pin number
22 W-BL Line in + W-BL 4
23 W-O Line out - W-O 9
47 Bl-W Line in - Bl-W 11
48 O-W Line out + O-W 2
Table 10-665. TN2242 administration
Field Value
Trunk Group form, Page 1
Trunk Type (in/out) wink, delay, immed
(all permutations)
Trunk Signaling Type blank
Answer Supervision Timeout 0
Receive Answer Supervision y
Disconnect Supervision - In? y
Disconnect Supervision - Out? y
Continued on next page
