VAL-BD (Voice Announcements over LAN Circuit Pack)
Issue 4 May 2002
10-1953 555-233-123
Packet Interface Test (#598)
This non-destructive test checks the packet bus interface circuitry on the VAL
circuit pack. Test failure indicates faulty circuit pack.
1-10 FAIL The circuit pack detects LAPD frame errors. The error code
indicates the value of the on-board error counter.
Retry the command at 1-minute intervals, up to 5 times.
If the test continues to fail, execute the Packet Interface Test
(#598) (test board UUCSS long).
If Packet Interface Test (#598) fails, see repair procedures for
Test (#598).
PASS Circuit pack detects no errors.
Table 10-698. TEST #598 Packet Interface Test
Error
Code
Test
Result Description/Recommendation
2000 ABORT Did not receive circuit pack test response within the allowable time
period.
Retry command at 1-minute intervals, up to 5 times.
If the problem persists, reset the circuit pack (reset board
UUCSS).
If the problem persists, replace the circuit pack.
2012 ABORT Could not allocate the necessary system resources to run test.
2100 ABORT Internal system error.
Retry the command at 1-minute intervals, up to 5 times.
If the problem persists, escalate the problem.
Continued on next page
Table 10-697. TEST #597 Invalid LAPD Frame Error Counter Test — Continued
Error
Code
Test
Result Description/Recommendation
Continued on next page
