VAL-BD (Voice Announcements over LAN Circuit Pack)
Issue 4 May 2002
10-1959 555-233-123
Faceplate LEDs
The following figure shows the 9 LEDs on the TN2051AP faceplate. Descriptions
of each LED are in Table 10-701.
Figure 10-105. TN2501AP faceplate LEDs
The following table lists the TN2501AP faceplate LEDs, the type of behavior (on,
off, flashing, or intermittent), and a description of the condition.
LINK
TRMT
RCV
100M
FDX
COL
