change system-parameters maintenance
Issue 4 May 2002
8-43555-233-123
Output (page 3)
Field descriptions (page 3)
Modem Connection
On page 3 of the example forms, 11 fields disappear when the Modem
Connection? field is set to internal. In this example the Modem Connection
field is set to external, revealing the 11 fields.
The first 2 fields on page 3 help setup the data format for the serial data from the
switch to the modem.These fields are display-only, and they must contain the
following values:
■ Data Bits = 8, Parity = None
The remaining fields are listed below.
Modem
Connection
Valid entries are internal or external.
Modem Name
This field is 20 characters long and will permit alpha-numeric
characters to provide a unique qualifier for a given modem. ()
RTS/CTS
Enabled
This field will inform the modem that communication with the
data source UART will be driven with RTS/CTS flow control.
This field is 6 characters long and is case in-sensitive. (\Q3)
change system-parameters maintenance Page 3 of 3
MAINTENANCE-RELATED SYSTEM PARAMETERS
Modem Connection: external
Data Bits: 8
Parity: none
Modem Name: _______
RTS/CTS Enabled: \Q3 Auto Answer Ring Count (rings):
S0=10
Asynchronous Data Mode: &M0&Q0 Dial
Type: T
DTE Auto-Data Speed: ______ Adjustable Make/Break
Ratio:
Disable Data Compression: ______ Dial
Command: D
Enable Error Control: ______ No Answer
Time-out: S7=255
Misc. Init. Param: ______________
To Next Page
