list configuration
Issue 4 May 2002
8-141555-233-123
Output
The following display shows the output from list configuration all.
Field descriptions
Board Number The functional name of the circuit pack
Code
The TN or UN code and suffix of the circuit packs
NOTE:
The letter P (programmable) is added to the suffix of
all the downloadable boards in the following forms:
■ list configuration
■ status firmware download
■ change firmware download
Vintage
The vintage number of the circuit pack
no board
The circuit pack is administered but not physically installed
conflict
The circuit pack administered to the slot differs from the circuit
pack that is physically installed
no link
The T1 link is down to a DS1 circuit pack
list configuration all Page 1
SYSTEM CONFIGURATION
Board Assigned Ports
Number Board Type Code Vintage u=unassigned t=tti p=psa
01C02 ATM PNC EI TN2305 HW02 FW102
01C03 ATM PNC EI TN2305 HW02 FW102
01C04 DIGITAL LINE no board 01 02 03 u u u u u
01C05 ANALOG LINE no board 01 u u u u 06 u u
u u u u u u u u
01C07 DS1 INTERFACE TN464F 000006 u u u u u u u u
u u u u u u u u
u u u u u u u u
01C08 DID TRUNK TN753 000021 u u u u u u u u
01C12 DS1 INTERFACE TN464FP HW02 FW063 u u u u u u u u
u u u u u u u u
u u u u u u u u
01C16 DS1 INTERFACE TN2405AP HW03 FW02 01 u u 04 u u u u
u u u u u u u u
u u u u u u u u
Enter 5 character board number; cabinet(1-30):carrier(A-E):slot(0-20)
12345678911234567890123456789012345678901234567890123456789012345678901234567890
