Maintenance Commands and Trouble-Clearing Aids
555-233-123
8-168 Issue 4 May 2002
Output
The following example shows the IP Codec Hourly Output For Region 4.
Field descriptions
Meas Hour
The hour the measurement was taken. Switches in multiple time zones
are treated as in the current MMI reports. We do not assume that there
is a correlation between LAN regions and time zones.
Range: 0000 - 2300.
Region
The network region that the IP Media Processors and Medpros for this
measurement are in. Range: 1-44.
DSP Rscs
Total IP codec resources (voice channels) in the region. (22 or 31) * #
Medpro + 64 * #IP Media Processors. The 22 or 31 multiplier for
Medpro depends on admin of codec preferences. A G711 call takes 1
resource, while a G723/729 call or a Fax relay call takes 2 resources.
Range: 0-9999.
G.711
Usage
(ERL)
Usage in Erlangs of G.711 codecs during the measurement interval.
Includes time that the voice channels are on a call. Use is measured
from the time the voice channel is allocated until it is released.
Calculated by:
(Total Call Seconds) / 3600 where Total Call Seconds is a sum of the
following:
total time (in seconds) that a G.711 resource on a Medpro is in use
total time (in seconds) that a G.711 resource on an IP Media
Processor is in use r
Range: 0-9999.
G.711 In
Reg Peg
Total number of times an IP media processor port in the region was
allocated to a G.711 call. Range: 0-65535.
list measurements ip codec hourly 4
Switch Name: Date: 5:32 pm WED MAR 26, 1992
IP CODEC RESOURCE HOURLY REPORT
G711 G723/9
--------------------- -------------------------
Meas DSP Usage In Reg Out of Usage In Reg Out of
Hour Region Rscs (Erl) peg Reg peg (Erl) peg Reg peg
0400 4 xxxx xxxx.x xxxxx xxxxx xxxx.x xxxxx xxxxx
0300 4 xxxx xxxx.x xxxxx xxxxx xxxx.x xxxxx xxxxx
0200 4 xxxx xxxx.x xxxxx xxxxx xxxx.x xxxxx xxxxx
0100 4 xxxx xxxx.x xxxxx xxxxx xxxx.x xxxxx xxxxx
0000 4 xxxx xxxx.x xxxxx xxxxx xxxx.x xxxxx xxxxx
2300 4 xxxx xxxx.x xxxxx xxxxx xxxx.x xxxxx xxxxx
2200 4 xxxx xxxx.x xxxxx xxxxx xxxx.x xxxxx xxxxx
