status conference
Issue 4 May 2002
8-349555-233-123
Field Descriptions
AUDIO
(cont’d.)
Other possible AUDIO mode values include neutral
(neutralized I-channel),
Au-off, and Frm (no audio signal)
which never match conference modes and are unsupported by
MCU.
56/64
The 65/64 field derestricts when operating at 64kbps,
128kbps, 192kbps, 256kbps, 320kbps, 384kbps, 512kbps, 768
kbps, 1472kbps, 1536kbps, or 1920kbps per channel speeds;
it
restricts when operating at 56kbps, 112kbps, 168kbps,
224kbps, 280kbps, 336kbps, 448kbps, and 672kbps per
channel speeds.
If technicians configure the conference for Nx56kbs
operations, endpoint may signal by capabilities or modes that
operate at the proper rate. In such a case, when technicians
receive derestrict commands while they are in the
restrict mode, that do not match conference
communication modes, (
MISC capability has restrict
displayed on Page 4) the
STAT 56/64 is y indicating 56/64
compatibility between the conference and the endpoint.
VIDEO
The Video mode: H.261 (recommended), H.CTX
(proprietary),
H.CTX+ (proprietary), or SG4 (proprietary)
indicate that video is on in the direction indicated;
and
video-off
when the video is off.
MLP
Multi Layer Protocol data mode. When technicians administer
Data Modes as any-mlp or ww-pcs, MLP modes should
be
var-MLP. Other values affect video status.
MLP modes should be MLP-off when technicians administer
Data Modes as
none. Other values in this mode affect video
status.
H_MLP
The High Speed MLP mode. The HMLP mode should be
H-MLP-off. Other values in this mode affect video status.
LSD
Low Speed Data mode. The LSD mode should be LSD-off.
Other values in this mode affect video status.
HSD
High Speed Data mode. The HSD mode should be HSD-off.
Other values in this mode affect video status.
CRYPT
Encryption mode. The CRYPT mode should be
encrypt-off. Other values in this mode affect video
status.
S/M
Single/Multi channel interoperability mode. 6B-H0-comp
indicates that the sender is interoperating multiple channels
and a single channel (for example, 6B and H0).
Not-comp-6B-H0 indicates that the sender is not
interoperating between 6B and H0. Normally this value is
Not-comp-6B-H0. Other values in this mode affect video
status.
