Maintenance Commands and Trouble-Clearing Aids
555-233-123
8-348 Issue 4 May 2002
Field descriptions
XRATE
(cont’d.)
XRATE may be 64 when the endpoint dials in, or in the event
that problems occur. It implies that only one B channel is in use.
AUDIO
Conference and endpoint Audio rates (kbps bandwidth) must
be the same. Their modes are not necessarily the same. When
the audio rate of the conference and the endpoint differ, the
endpoint’s audio interworks, but the endpoint’s video is invalid.
MCU may or may not send video to such an endpoint.
Table 8-13 on page 8-348 summarizes expected endpoint
audio modes with different transfer rate configurations, facility
bandwidths, and conference modes. It includes endpoints that
support the highest common audio mode (HC audio) when the
administered mode is
auto. The highest common conference
mode depends on the administered bandwidth. A ‘-’ in the table
indicates ‘does not apply.’
Table 8-13. Audio Mode Configurations
Admin
Mode (HC
Audio)
All
Support
HC
Audio
Xfer
Rate
Facility
BW Conf Mode Expected Endpoint Mode
auto (G.728) yes <=128k - G.728 G.728
auto (G.728) no <=128k 64k G.711-A-56k G.711-A-56k B.711-Mu-56k
auto (G.728) no <=128k 56k G.711-A-48k G.711-A-48k G.711-MU-48k
auto (G.722) - >128k 64k G.722-56k G.722-56k G.711-A-56k
G.711-Mu-56k
auto (G.722) - >128k 56k G.722-48k G.722-48k G.711-A-48k
G.711-Mu-48k
G.728 - - G.728 G.728
G.711 - - 64k G.711-A-56k G.711-A-56k G.711-Mu-56k
G.711 - - 56k G.711-A-48k G.711-A-48k G.711-Mu-48k
G.722 - - 64k G.722-56k G.722-56k G.711-A-56k
G.711-mu-56k
G.722 - - 56k G.722-48k G.722-48k G.711-A-48k
G.711-Mu-48k
Continued on next page
