ANL-24-L (24-Port Analog Line)
Issue 4 May 2002
10-51 555-233-123
2000 ABORT Response to the test request was not received within the
allowable time period.
2100 ABORT System resources required to run this test are not available.
1. Look for TONE-PT errors in the error log. If present, refer
to “TONE-PT”.
2. If there are no TONE-PT errors in the error log, retry the
command at 1-minute intervals a maximum of 5 times.
Any FAIL The NPE of the tested port did not conference the tones
correctly. This will cause noisy and unreliable connections.
1. Issue the display port and the status station commands
to determine if the station is idle. If the station is idle, issue
the test port command for this port.
2. If the test continues to fail, issue the busyout port and
the release port commands, and then retest.
3. If the test still fails, replace the board.
PASS The port can correctly conference multiple connections.
User-reported troubles on this port should be investigated by
using other port tests and by examining station, trunk, or
external wiring.
0NO
BOARD
The test could not relate the internal ID to the port (no board).
This could be due to incorrect translations, no board is
inserted, an incorrect board is inserted, or an insane board is
inserted.
1. Check to ensure that the board translations are correct.
Use the list config command, and resolve any problems.
2. If the board was found to be correctly inserted in step 1,
issue the busyout board command.
3. Issue the reset board command.
4. Issue the release busy board command.
5. Issue the test board long command. This should
re-establish the linkage between the internal ID and the
port. If this is not the case, check to ensure that there is a
valid board inserted.
Table 10-19. TEST #7 Conference Circuit Test — Continued
Error
Code
Te s t
Result
Description/Recommendation
Continued on next page
