ATM-DCH (ATM D-Channel Port)
Issue 4 May 2002
10-209 555-233-123
Hardware Error Log Entries and Test to Clear
Val ues
Notes:
a. Error Type 18: D-channel busied out; no calls possible over this D-channel.
b. Error Type 130: circuit pack removed or has been insane for more than 11
minutes. To clear the error, reinsert or replace the circuit pack.
c. Error Type 1793: ATM Trunk circuit pack failed the Signaling Link Board
Check (#643). Resolve any ATM-TRK errors in the Error Log.
System Technician-Demanded Tests:
Descriptions and Error Codes
The command to test the ATM-DCH maintenance object is test port UUCSSpp,
where pp is for ports 9-32.
Table 10-73. ATM D-channel Error Log entries
Error
Type
Aux
Data Associated Test
Alarm
Level
On/Off
Board Test to Clear Value
0
1
1 Run the Short Test Sequence first. If all tests pass, run the Long Test Sequence. Refer to the
appropriate test description and follow the recommended procedures.
0 Any Any Any test port UUCSSpp
2
2 pp is for ports 9-32.
18 (a) 0 busyout port UUCSSpp WARNING OFF release port UUCSSpp
130 (b) None WARNING ON test port UUCSSpp
1793 (c) Signaling Link Board Check
(#643)
test board UUCSS l
Continued on next page
Table 10-74. System Technician-Demanded Tests: ATM-DCH
Order of Investigation
Short Test
Sequence
Long Test
Sequence D/ND
1
1 D = Destructive, ND = Nondestructive
Signaling Link Board Check (#643) X X ND
To Next Page
