Engine
SHOP MANUAL
Ch 1 page 169
7. Press on the new bearing.
8. Remove the screws and the washer securing the bearing in the
front housing.
9. Put a sleeve on the bearing and tap out the old bearing from the
front housing.
10. Fit a new bearing. Fit the front housing in the vice and press it
into position using a sleeve on the outer race.
The refit the washer and tighten the 4 screws.
Figure 330
Figure 329
Figure 331
Figure 332
