SHOP MANUAL
DRIVE LINE
Ch 3 page 120 Ch 3 page 121
DRIVE LINE
Remove spider shafts and axle bevel gears (see Figure 353)
out of the differential housing.
Remove the second axle bevel gear.
Lift the pressure ring out of differential housing and
remove the disk package and thrust washers behind.
Support crown wheel and press the differential housing
out.
Disassembly
Figure 356
Figure 355
Figure 354
Figure 353
