Doosan DA40 - Page 489

SHOP MANUAL
DRIVE LINE
Ch 3 page 126 Ch 3 page 127
DRIVE LINE
Insert pressure piece (see arrow) and install disk.
Insert compression springs (6x) into the differential cover.
Insert sliding sleeve.
Preload the compression springs by means of the press
and engage the retaining ring into the annular groove of
the sliding sleeve.
Reassembly
Figure 375
Figure 374
Figure 373
Figure 372
