SHOP MANUAL
DRIVE LINE
Ch 3 page 128 Ch 3 page 129
DRIVE LINE
Insert the axle bevel gear until contact is obtained and
install the inner disks with the teeth.
Preassemble the differential spider and insert it into the
differential housing /into the pressure ring.
Mount second axle bevel gear.
Insert the second pressure ring into the differential
housing.
Reassembly
Figure 387
Figure 386
Figure 385
Figure 384
